HVAC & IAQ

Healthy Air Must Flow

Imagine the HVAC in your facility failing ten or twenty years ago. After the repair bill hit, a decision would be made to avoid that cost in the future, taking operating expenses and asset lifecycles into account. The smart people in the room would try to weigh the human cost of discomfort due to lost temperature and humidity control, but it’s hard without clear numbers. A plan would be made, a consensus built, hands shaken, and things would move forward.

Today, the handshakes may feel like signs of a simpler time, but it is the evaluation of costs that should really concern us. A very big risk has not been accounted for that is very clear to us now, after the events of 2020. What was missed?

man cleaning ventilation screen

PHOTO CREDIT ELNUR

In our imaginary building ten years ago, there was also a significant rise in sick days the following week. Even if someone connected the rash of colds to the lack of good airflow, that concern did not make it up the chain to the decision makers.

The truth is, building owners and operators are very well-practiced at accounting for the cost of repairing or replacing a failed piece of equipment. Failed ventilation itself, on the other hand, has many more risks that owners and operators are less practiced at accounting for—but that should no longer be left off the list. And while the discomfort of poor temperature control has real impacts on performance, when the HVAC goes down, buildings lose more than temperature control. Lack of airflow and humidity control can both lead to increased exposure to pollutants and pathogens.

The Cost of Poorly Maintained Ventilation Systems

The financial impact of a pandemic event like COVID-19 may be incalculable. Before the SARS-CoV-2 virus, however, experts were already working hard to expand our understanding of poor indoor air quality and educate the public about those risks and costs. In fact, indoor air was believed to be a major environmental factor by 1850. The fact that we spend 90% of our time indoors is often cited to give crucial context to the EPA’s finding that certain indoor pollutant levels were 2 to 5 times larger than the concentrations outside.

As our understanding of indoor air quality issues has grown, ASHRAE (the American Society of Heating, Refrigerating and Air-Conditioning Engineers) has set and raised standards for ventilation to protect indoor air and the people who breathe it. Standards help make it clear that a poorly maintained ventilation system can lead to a sub-standard indoor environment, but the costs of those risks depend on the various health impacts studied. One study cites the annual cost of care for upper and lower respiratory tract infections at $36 billion and the cost of lost work at $34 billion. The same study found that 23% of office workers reported symptoms of sick-building syndrome improved away from their work environments—and calculates the cost of sick-building syndrome to businesses nationwide at $60 billion.

Another way of looking at the cost of indoor air quality is the opportunity lost: The benefits of improved indoor environments have been calculated to be 18 to 47 times greater than the costs.

HVAC Downtime Can Be Avoided

For ventilation to remain adequate for our indoor environments, the HVAC equipment responsible for that ventilation simply cannot break down. HVAC systems have evolved to improve efficiency and give us better control over environments, and those systems have multiple components that should be properly cared for to avoid issues—from compressors and coils to variable-speed fans and high-efficiency filters.

Since the COVID-19 pandemic, standards organizations ASHRAE and the CDC have both stressed the importance of increasing ventilation to reduce pathogen counts in shared spaces. Their recommendations include discontinuing the use of demand controls that may reduce ventilation and increasing airflow to spaces when occupied. Taking these steps may increase the load on an HVAC system, and a poorly maintained system is less equipped to stay operational and efficient under those conditions.

Guidance on increasing filtration for HVAC systems also notes that increasing filter efficiency can lead to reduced airflow. Compensating can increase energy use as fans and components work harder. A poorly maintained system is also in danger of responding inadequately to those needs.

When the System Is the Problem

A poorly maintained HVAC system can itself be a source of indoor pollutants. Filters, air ducts, cooling coils, and drain pans are all examples of failure points where lack of attention can introduce unwanted contaminants.

Imagine a food safety inspector asking why a restaurant’s kitchen is so filthy, and the owner responding, “Well, we cleaned it when it was built.” The food we eat shouldn’t be produced by a contaminated system, and the air we breathe shouldn’t arrive through one.

Poorly maintained cooling coils, drip pans, or cooling towers have been found to be the cause of respiratory diseases (like legionnaires). According to one estimate, the interior surface area of air ducts is 10% of the floor of office spaces, and dust accumulation there can promote the growth and release of micro-organisms and metabolic products into the air.

Just Open a Window?

When indoor ventilation breaks down, simply opening a window may feel like a great temporary fix. However, not every facility has this option, and the sad truth is that exposure to outdoor air carries risks that we’re also continuing to learn about. A Stanford-led study from 2021 found that children’s exposure to outdoor pollutants, even for only a single day, led to changes in gene expressions that impacted their long-term chances of heart disease.

Limited access to outdoor air is also a problem during a facility’s response to indoor pathogen spread. In recommendations for reducing exposure to SARS-CoV-2, the virus that causes COVID-19, the CDC noted that opening windows could reduce the concentration of viral particles inside. That recommendation is hedged with important caveats, however, such as to use caution in highly polluted areas. In fact, the CDC goes on to recommend, “Ensure ventilation systems operate properly and provide acceptable indoor air quality for the current occupancy level for each space.”

It’s Not All Downside

Studies show that improving indoor air quality has positive effects. A 2015 study found that enhanced ventilation, including reduction in volatile organic compounds, led to increased cognitive performance scores and improvements in information usage and crisis response. Enhancing ventilation may increase an HVAC system’s load, but a well-maintained and optimized system can help a facility deliver the benefits of improved indoor air quality in a cost-effective manner.

The Time Is Now

Given the health risk that poor indoor air quality poses to the people who share the air in our facilities, it may be time to consider HVAC a mission-critical asset. The first step in improving the indoor air quality in our facilities is ensuring that ventilation meets or exceeds the clear guidelines for airflow. Keeping those systems running optimally may be a cost, but when compared to the risks of poor ventilation passed on to the people in our facilities, the benefits of proactive maintenance are clear.

This article originally appeared in the Spring 2021 issue of Spaces4Learning.
